| Packaging Configuration | |||
|---|---|---|---|
| ( Two pallets = One stack ) | |||
| 36pcs/pallets,72pcs/stack,936pcs/40’HQ Container |
| Mechanical Characteristics | |||
|---|---|---|---|
| Cell Type | P type Mono-crystalline | ||
| No. of cells | 108 (2×54) | ||
| Dimensions | 1722×1134×30mm | ||
| Weight | 22.20kg (48.50 lbs) | ||
| Front Glass | 3.2mm,Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass | ||
| Frame | Anodized Aluminium Alloy | ||
| Junction Box | IP68 Rated | ||
| Output Cables | TUV 1×4.0mm2 (+): 290mm , (-): 145mm or Customized Length | ||
| SPECIFICATIONS | |||||
|---|---|---|---|---|---|
| Module Type | JKM440M-60HL4 JKM440M-60HL4-V | JKM445M-60HL4 JKM445M-60HL4-V | JKM450M-60HL4 JKM450M-60HL4-V | JKM455M-60HL4 JKM455M-60HL4-V | JKM460M-60HL4 JKM460M-60HL4-V |
| STC NOCT | STC NOCT | STC NOCT | STC NOCT | STC NOCT | |
| Maximum Power (Pmax) | 440Wp 327Wp | 445Wp 331Wp | 450Wp 335Wp | 455Wp 339Wp | 460Wp 342Wp |
| Maximum Power Voltage (Vmp) | 33.72V 31.39V | 33.82V 31.56V | 33.91V 31.73V | 34.06V 31.91V | 34.20V 32.07V |
| Maximum Power Current (Imp) | 13.05A 10.43A | 13.16A 10.49A | 13.27A 10.55A | 13.36A 10.61A | 13.45A 10.67A |
| Open-circuit Voltage (Voc) | 41.02V 38.72V | 41.10V 38.79V | 41.18V 38.87V | 41.33V 39.01V | 41.48V 39.15V |
| Short-circuit Current (Isc) | 13.73A 11.09A | 13.79A 11.14A | 13.85A 11.19A | 13.93A 11.25A | 14.01A 11.32A |
| Module Efficiency STC (%) | 20.39% | 20.62% | 20.85% | 21.08% | 21.32% |
| Operating Temperature(℃) | -40℃~+85℃ | ||||
| Maximum system voltage | 1000/1500VDC (IEC) | ||||
| Maximum series fuse rating | 25A | ||||
| Power tolerance | 0~+3% | ||||
| Temperature coefficients of Pmax | -0.35%/℃ | ||||
| Temperature coefficients of Voc | -0.28%/℃ | ||||
| Temperature coefficients of Isc | 0.048%/℃ | ||||
| Nominal operatingcell temperature (NOCT) | 45±2℃ | ||||
